REFERENCE DESIGNS:
AC TO DC FRONT-END ONLY
Our AC to DC front-end reference designs include a Pulsiv OSMIUM microcontroller and support a variety of different features and power levels. Once a configuration has been selected, simply integrate a suitable DC to DC converter to produce a complete power supply design.
| Reference Design Number |
Output Power Range |
Input Voltage Range |
HVDC Range | Efficiency | Hold Up | Half Active Bridge |
X-Cap Discharge |
View Full Spec & Documents |
|---|---|---|---|---|---|---|---|---|
| PSV-CCAD-150 | 1W – 150W | 85 – 265VAC | 80 - 380VDC | Average: 97.5% Peak: 99.5% |
VIEW | |||
| PSV-CCAD-150H | VIEW | |||||||
| PSV-CCAD-250 | 1W – 250W | UNDER DEVELOPMENT | ||||||
| PSV-CCAD-250H | UNDER DEVELOPMENT | |||||||
| PSV-CCAD-250X | UNDER DEVELOPMENT | |||||||
| PSV-CCAD-250A | UNDER DEVELOPMENT | |||||||
| PSV-CCAD-250HX | UNDER DEVELOPMENT | |||||||
| PSV-CCAD-250AH | UNDER DEVELOPMENT | |||||||
IMPORTANT: The values of Lch, Rch, and Cch must be calculated for the desired output power. We provide a FREE MS Excel calculator tool for this purpose which can be found by viewing the full specification and documents link next to each reference design number.
